Raymarine CP470 User Manual

•R
aymarinespecifiedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedintheinstallationmanual.
Note:
Whereconstraintsontheinstallationpreventanyoftheaboverecommendations,alwaysensure
themaximumpossibleseparationbetweendifferentitemsofelectricalequipment,toprovidethe
bestconditionsforEMCperformancethroughouttheinstallation.
Compasssafedistance
T opreventpotentialinterferencewiththevessel'smagneticcompasses,ensureanadequate
distanceismaintainedfromtheproduct.
Whenchoosingasuitablelocationfortheproductyoushouldaimtomaintainthemaximumpossible
distancefromanycompasses.Typicallythisdistanceshouldbeatleast1m(3.3ft)inalldirections.
Howeverforsomesmallervesselsitmaynotbepossibletolocatetheproductthisfarawayfroma
compass.Inthissituation,whenchoosingtheinstallationlocationforyourproduct,ensurethatthe
compassisnotaffectedbytheproductwhenitisinapoweredstate.
DeclarationofConformity
FLIRBelgiumBVBAdeclaresthatthefollowingproductsareincompliancewiththeEMCDirective
2014/30/EU:
•CP370Sonarmodule,partnumberE70297
•CP470Sonarmodule,partnumberE70298
•CP570Sonarmodule,partnumberE70258
TheoriginalDeclarationofConformitycertificatemaybeviewedontherelevantproductpageat
www.raymarine.com/manuals.
Connectionstootherequipment
Requirementforferritesonnon-Raymarinecables
IfyourRaymarineequipmentistobeconnectedtootherequipmentusingacablenotsuppliedby
Raymarine,asuppressionferriteMUSTalwaysbeattachedtothecableneartheRaymarineunit.
Productdisposal
DisposeofthisproductinaccordancewiththeWEEEDirective.
TheWasteElectricalandElectronicEquipment(WEEE)Directiverequirestherecyclingofwaste
electricalandelectronicequipmentwhichcontainsmaterials,componentsandsubstancesthatmay
behazardousandpresentarisktohumanhealthandtheenvironmentwhenWEEEisnothandled
correctly.
Equipmentmarkedwiththecrossed-outwheeledbinsymbolindicatesthattheequipment
shouldnotbedisposedofinunsortedhouseholdwaste.
Localauthoritiesinmanyregionshaveestablishedcollectionschemesunderwhichresidentscan
disposeofwasteelectricalandelectronicequipmentatarecyclingcenterorothercollectionpoint.
Formoreinformationaboutsuitablecollectionpointsforwasteelectricalandelectronicequipmentin
yourregion,refertotheRaymarinewebsite:www.raymarine.com/manuals.
Warrantyregistration
ToregisteryourRaymarineproductownership,pleasevisitwww.raymarine.comandregisteronline.
Importantinformation
