Raymarine CP470 User Manual

4.5Networkconnection
TheunitmustbeconnectedtoacompatibleR
aymarinemultifunctiondisplaytoenableechosounder
datatobeviewed.
Multifunctiondisplayconnection
UnitconnectedtoamultifunctiondisplayusingaRayNetcable.
Note:Theconnectionpanelonyourproductmaylookslightlydifferenttothatshown,depending
onvariant.ThenetworkconnectionmethodremainsthesameforallproductsfeaturingR ayNet
connectors.
ItemDescription
1
Sonarmodule(CP370illustrated).
2ConnectorpanelforcompatibleR aymarinemultifunctiondisplay.
3
R ayNetcable.
Multifunctiondisplayconfiguration(e xtendedcables)
Whentherequiredlengthofasinglenetworkcablerunisgreaterthan20m(65.6ft),aRayNet(male)
to(male)adaptorcableshouldbeusedtoconnectRayNetcablestogether.
Note:Theconnectionpanelonyourproductmaylookslightlydifferenttothatshown,depending
onvariant.ThenetworkconnectionmethodremainsthesameforallproductsfeaturingR ayNet
connectors.
62
