Dualtransducerconnections
ItemDescription
1
CP370
2
DualSpeedandT emperaturetraditionaltransducercable(partnumberE66022)
3Cabletotransducerconnection
4
Cabletotransducerconnection
5
T raditionaltransducer(e.g.Depth)
6
T raditionaltransducer(e.g.SpeedandTemperature)
R efertotheRaymarinewebsiteforalistoftransducersthatarecompatiblewithyoursonarmodule:
www.raymarine.com/transducers.
Foralistoftransducercablesreferto10.1Sparesandaccessories.
CP470/CP570Transducerconnections
TheCP470isaClearPulse
TM
CHIRPbroadbandsonarmoduledesignedforusewithbroadband
transducers.
TheCP570isaClearPulse
TM
CHIRPdual-channelbroadbandsonarmoduledesignedforusewith
broadbandtransducers.
Note:T ransducerswithoutTransducerID
®
arenotsupported.
Checkthewebsitewww.raymarine.comforinformationabouttransducersthatarecompatiblewith
yourCP570sonarmodule.
Important:T ransducersmustbeinstalledinaccordancewiththeinstructionsprovidedwiththe
transducer.
ThefollowingconnectiondiagramsshowaCP470sonarmodule ,butalsoapplicabletotheCP570
sonarmodule.
Cablesandconnections55
