equiredadditionalcomponents
Thisproductformspartofasystemofelectronicsandrequiresthefollowingadditionalcomponents
forfulloperation.
•Compatibletransducer:transom,through-hull,in-hull,orpocket/keelmount.Refertothe
Raymarinewebsiteforalistoftransducersthatarecompatiblewithyoursonarmodule:
www.raymarine.com/transducers.RefertoCP370:EMCcomplianceforinformationaboutregional
restrictionsthatapplytotransducersusedwiththeCP370sonarmodule.
•CompatibleRaymarinemultifunctiondisplay.RefertoCompatiblemultifunctiondisplaysfora
listofcompatibleproducts.
•Datacables.RefertoChapter4Cablesandconnectionsforsuitablecables.Someinstallations
mayalsorequireextensionstodata,powerortransducercables.RefertotheChapter4Cables
andconnectionsandChapter10Sparesandaccessoriessectionsformoreinformation.
CP370:EMCcompliance
Important:T oensureEMCCompliance,thetransducerslistedbelowareNOTcertifiedtobe
usedwiththeCP370inthefollowingregions:
•Australia;
•NewZealand;
•anymemberstateoftheEuropeanEconomicArea(EEA);
•EuropeanFreeTradeAssociationcountriesIceland,Liechtenstein,NorwayandSwitzerland;
•anycountrythatrequiresEMCDirectiveCompliance.
Ifindoubt,pleasecontactyourlocaldealerorRaymarinetechnicalsupport.
T ransducersNOTcertifiedtobeusedwiththeCP370intheregionslistedabove:
•E66054(P66,Plastic,Transommount)
•E66008(P79,Plastic,In-hull)
•A66091(B744V,Bronze,Through-hull)
•A66092(B744VL,Bronze,Through-hull)
•E66013(P319,Plastic,Through-hull)
•E66014(B117,Bronze,Through-hull)
•E66085(B60–20°,Bronze,Tiltedelement,Through-hull)
•E66086(B60–12°,Bronze,Tiltedelement,Through-hull)
Planningtheinstallation
29
