9
.1CP370Technicalspecification
Physicalspecification
Dimensions•Width:299
.4mm(11.79in).
•Height:205.6mm(8.1in).
•Height(includingconnectors):285.6mm
(11.2in).
•Depth:84.4mm(3.3in).
W eight
1.435kg(3.16lbs)
P owerspecification
Nominalsupplyvoltage
12V/24Vdc
Operatingvoltagerange
10 .8Vto31.2Vdc
P owerconsumption
30.6W(Maximum)
Current3ARMS
Fuse/break ers
5A
Environmentalspecification
Operatingtemperature
–10°C(14°F)to+55°C(131°F)
S toragetemperature
–30°C(22°F)to+70°C(158°F)
R elativehumidity
95%
W aterproofrating
IPX6
Sonarspecification
Frequency
50kHzand200kHz
P oweroutput
Upto1KWRMS
Depth
0 .9m(3ft)to1524m(5,000ft)(Inoptimumconditionsanddepending
ontransducerconnected)
T ransducerTransom-mount,in-hull,thru-hull
Connections
•1xP owerconnection
•1xnetworkconnection(RayNetconnector)10/100Mb/s
•1xTransducerconnection
Conformancespecification
Conformance•EN60945:2002
•EMCDirective2014/30/EU
•A
ustraliaandNewZealand:C-Tick,
ComplianceLevel2
88
