Raymarine CP470 User Manual

10
.2Networkhardware
ItemP
artnumberNotes
HS5R
ayNetnetworkswitch
A
800075–portswitchfornetworkconnection
ofmultipledevicesfeaturingRayNet
connectors.EquipmentwithRJ45
SeaTalk
hs
connectorscanalsobe
connectedusingsuitableadaptercables.
RJ45Sea Talk
hs
networkswitch E550588–portswitchfornetworkconnectionof
multipleSeaTalk
hs
devicesfeaturingRJ45
connectors.
RJ45Sea Talk
hs
crossover
coupler
E55060•EnablesdirectconnectionofRJ45
SeaTalk
hs
devicestosmallersystems
whereaswitchisnotrequired.
•EnablestheconnectionofRJ45
SeaTalk
hs
devicestoaHS5RayNet
networkswitch(inconjunctionwith
suitableadaptercables).
•Enables2RJ45Sea Talk
hs
cablesto
beconnectedtogethertoextendthe
lengthofthecabling.
Recommendedforinternalinstallations.
Important:DoNOTusecrossover
devicesforPOE(PowerOverEthernet)
connections.
EthernetRJ45coupler
R32142•EnablesdirectconnectionofRJ45
SeaTalk
hs
devicestosmallersystems
whereaswitchisnotrequired.
•EnablestheconnectionofRJ45
SeaTalk
hs
devicestoaHS5RayNet
networkswitch(inconjunctionwith
suitableadaptercables).
•Enables2RJ45Sea Talk
hs
cablesto
beconnectedtogethertoextendthe
lengthofthecabling.
Recommendedforexternalinstallations.
Sparesandaccessories
93
