Chapter 1: Operation 5
Additional functions in unlocked mode
When operating in unlocked mode, you can use the disp button to show the
following information on the digital display:
• Course over ground (COG). This is available if the ST60+ Compass Instrument
is connected via SeaTalk system to a compatible GPS. If GPS information is not
available, the digital display shows --- when COG is selected.
• Average heading.You can reset the average heading value by holding down
the
> button for 3 seconds.
.
Operating hints
Steering sense
When the pointer indicates an off course error, steer the vessel in the direction you
want the pointer to move.
Man overboard/reciprocal course
If the vessel is turned through 110° or more when the ST60+ Compass Instrument
is in lock mode, the ST60+ Compass Instrument automatically locks to the
reciprocal of the original course (180° from the original). The digital display shows
the reciprocal course and the pointer shows the course error from the reciprocal
course.
The reciprocal course function is reversible, so that a second similar turn would
lock onto the original locked course.
Note: The Man overboard/reciprocal course feature is not available when operating in
Auto mode.
Note: * relies on external data.
Information available in unlocked mode
Average
heading*
Course Over
Ground
(COG)*
Current
heading
TRUE MAG
Switch on
COG
TRUE MAGTRUE MAG
AVE
Press
for 3 seconds
to reset average
disp
disp
D8196-1
disp
81265_1.book Page 5 Monday, December 5, 2005 9:23 AM
