Dedicated Commands
20 Rev. B4 Aug 2019 MP150 Protocol
To get the width from the result sent via Ethernet you must use the following formula:
Width = result * (2 * Distance_Scanner_Object) / 8192
To get the width from the current output you must use the following formula:
Width = (I – SZ) / (SM – SZ) * (2 * Distance_Scanner_Object)
Where SZ (command Sector Zero) is usually 0/4 mA and
SM (command Sector Max) is usually 20 mA.
The commands SL and SR do lose their traditional function.
• SL is not used, and
• SR gives an offset in pixels to move the edges in the direction of the plateau centre.
The commands SB and ST do lose their traditional function too. They are fixed to 0 and 8192, the result
will be in this range.
Please take care with the offset! It adds inaccuracy to the result. The width of the plateau becomes
dependent on its position in the viewing field.
5.2.4 The Translation of Temperature into Current
The current output is defined by:
• the minimum temperature of the sector (command SB)
• the maximum temperature of the sector (command ST)
• the current corresponding to the minimum temperature (command SZ)
• the current corresponding to the maximum temperature (command SM)
5.2.5 How the Current / Temperature gets calculated?
The current / temperature gets calculated using the formula:
Temperature = (ST – SB) / (SM – SZ) * (Current – SZ) + SB
Current = (SM – SZ) / (ST – SB) * (Temperature – SB) + SZ
5.2.6 Sector Alarms
For each analog output and subsequently for each sector, an alarm condition can be defined (using the
commands Trigger Top TT and Trigger Bottom TB). Equally, an alarm condition can be defined for the
digital interface too (sector 0). These conditions are independently integrated such that the alarm will
be activated as soon as any one of the conditions is fulfilled.
The result of this integration is requested by the command GAR. If at least one alarm condition is
fulfilled, the command will return AR1, otherwise it will return AR0.
Example: To set an upper alarm limit for sector 1 at 200°C: TT10200.
