Service Manual 7.UHF3 (350-400 MHz) Information
197
No.
Ref. No.
Print No.
Part No.
Description
1034
U1006
T6G
ESH016000002
Power management IC
1035
U1010
T4F
ESH016000002
Power management IC
1036
U1011
T2D
ESH016000002
Power management IC
1037
U1012
T12H
ESH016000002
Power management IC
1038
U1013
T12H
ESH016000002
Power management IC
1039
U2008
B2H
ESH016000002
Power management IC
1040
Q5015
B5B
EFPS03020000
P-MOSFET
1041
U8003
B8B
ESE028000000
Current sense amplifier
1042
U7000
T10K
ESD017000000
PLL IC
1043
D6002
B12H
ESZ017000000
Mixer IC
1044
U2006
T4J
ESR002000000
Logic IC
1045
U5000
B3D
ESR002000001
Logic IC
1046
U5001
B3H
ESR002000001
Logic IC
1047
U5002
B5I
ESR002000001
Logic IC
1048
U3003
B5H
ESN002000001
Baseband processor IC
1049
U4000
B7I
ESF002000000
D/A converter IC
1050
U2003
B2J
ESQ002000001
Reset IC
1051
U1000
T6E
ESH002000000
Power management IC
1052
U1001
T6G
ESH002000001
Power management IC
1053
U3010
T3G
ESP002000000
Analog switch IC
1054
U3000
T2G
ESP002000001
Switch IC
1055
U3008
T2H
ESP002000001
Switch IC
1056
D1008
T4B
EDWS03070001
Zener diode
1057
D1004
T5C
EDWS03070000
Zener diode
1058
D2001
B2H
EDWS03070000
Zener diode
1059
Q6000
B13F
ETCS03080001
Compound transistor
1060
U501
T8J
ESY013000000
Buffer amplifier IC
1061
U2002
B2I
ESH018000000
Power management IC
1062
U4008
T2K
EGGS02447000
SAW filter
1063
U4009
T2K
ESB008000000
Bluetooth module
1064
X4001
T3K
EYBS02605002
Crystal resonator
1065
J1000
/
EJZS00600000
Power socket
1066
C1000
/
ECE00477M002
470 μF
1067
J5000
/
EJZS02600000
D_SUB connector
1068
U3009
/
ESV024000000
Audio amplifier IC
1069
J4000
/
EMC001000000
RF connector
1070
J4001
/
EMC001000000
RF connector
