Re WG251 SKB-B RESMART User Manual

Re S.p.A. WG251 SKB-B RESMART
Rev. 05/15 23/25
Technical specifications
 Power supply and consumption: 24Vdc ±7% - 2,5A
 Operating temperature: 10÷50°C
 Degree of protection: IP54
 Weight: 10Kg
 Max length of the supply cable: 10m
 Detection range of the sensor: +/- 2,5mm
 Sensor fork width: 25mm
 Resolution of the sensor: 0,010mm
 Ultrasound frequency of the sensor: 220kHz
 Response time of the sensor: 3,5msec
Maintenance
Caution!
Before performing any operation on the WG251 SKB-B RESMART whatsoever, turn the
voltage supply off.
To ensure that the webguide WG251 SKB-B RESMART operates efficiently:
 check the condition of the cables regularly;
 keep the sensor capsules clean.
The frequency at which these operations are performed depends on how the webguide is used.
To avoid malfunctioning, be careful also not to expose the sensor to direct draughts.
Disassembly and dismantling
Caution!
Before dismantling the WG251 SKB-B RESMART, turn the voltage supply off.
To disassemble the webguide from the machine simply remove the 4 screws from the support table on
the outer box (see figure on page 3).
When disassembling and dismantling the webguide always wear
safety gloves and boots and observe all the safety norms required for
the environment in which it is located.
