Redarc BMS1215S2 User Manual

3 USER GUIDE
3.4 Troubleshooting
The Redarc BMS is one of the most advanced Battery Management Systems on
the market. It has been designed to detect and advise the operator of a variety
of fault conditions and will terminate the charging cycle immediately should a
critical fault be detected. This ensures that it will not attempt to charge a faulty
battery, which protects the BMS, house battery and most importantly the user.
The Remote Display is used to inform the user of the nature of the problem
whenever possible. These indicators should be used to diagnose, and if possible
correct any faults that may occur. If after attempting to rectify the situation,
a fault still occurs, please send the unit back to Redarc for diagnosis. When
attempting to diagnose a fault, cabling should be over-rated and all components,
including all input sources and house battery should be connected as close as
possible to the BMS.
BMS FAULT MESSAGE CAUSE ACTION
BMS over current fault An internal error has caused excessive
current draw
Return to supplier
Output battery over voltage fault The output battery voltage is too high
(above 18V)
Check battery is correct type (12V, 6
cell)
Internal temp sensor short circuit fault There is an error with the internal
temperature sensor
Return to supplier
Internal temp sensor open circuit fault There is an error with the internal
temperature sensor
Return to supplier
Unit over temperature fault. Allow to cool The unit has over heated Allow to cool, charging will recom-
mence automatically
Output battery under temperature fault Output battery is below 0°C BMS will halt charging until battery is
above 5°C
Output battery over temperature fault Output battery is above 60°C BMS will halt charging until battery is
below 55°C
Internal solar relay open circuit fault There is an error with an internal relay Contact supplier
Internal solar relay short circuit fault There is an error with an internal relay Contact supplier
Internal DC relay open circuit fault There is an error with an internal relay Contact supplier
Internal DC relay short circuit fault There is an error with an internal relay Contact supplier
Internal output relay open circuit fault There is an error with an internal relay Contact supplier
Internal output relay short circuit fault There is an error with an internal relay Contact supplier
Dry cell detected in output battery BMS ha sdetected a dry cell in output
battery
Replace battery
Shorted cell detected in output battery BMS has detected a shorted cell in
output battery
Replace battery
Fault detected in output battery BMS has detected a fault in output
battery
Replace battery
31
