— English Fillcontrol Plus — 06.07.2016 - Rev. B
9.2.1 Customer menu
The device controller is shipped with the following default settings. Use the Customer menu to adjust these values to local conditions. In
special cases, it is possible to further adjust the values in the Service menu.
Customer menu
Language EN Display language
Fillcontrol XX Magcontrol
For systems with diaphragm-type pressure expansion
tank
Minimum operating pressure p0 1.5 bar Only Magcontrol
see chapter 7.2 "Determining the P
0
minimum operating
pressure for the controller" on page 24 .
Safety valve, pressure 3.0 bar
Pressure value for the safety valve of the heat generator
in the system to trip
Next maintenance 12 months Time left to the next due maintenance
Floating alarm contact NO Only the messages marked in the "Messages" list
Makeup
Maximum makeup quantity 5000 Litres Only if controller with "With water meter yes"
Maximum makeup time 20 minutes Magcontrol
Maximum makeup cycles 3 cycles within 2 hours Magcontrol
Softening (Only if "With softening yes")
Lock makeup No In the case of soft water residual capacity = 0
Hardness reduction 8°dH = Target – Actual
Attainable makeup quantity
Soft water capacity 0 Litres Attainable water capacity
Cartridge replacement 18 months Replace cartridge
9.2.2 Service menu
This menu is protected with a password. It can be accessed only by the Reflex Customer Service. A partial summary of the settings stored
in the Service menu is proved in the Chapter Default settings, see chapter 9.2.2 "Service menu" on page 34 .
Service menu
Pressure differential, "NSP" makeup 0.2 bar Only Magcontrol
Pressure differential, filling pressure PF – P
0
0.3 bar Only Magcontrol
Water quantity for each contact
Only if a water meter is installed.
Maximum filling contacts OFF Limits the filling volume.
Only if a water meter is installed.
