12. Appendix
Table 8. System fuses
Table 9. Installed major components and identification tags
The spare parts listed in Table 10
are recommended to prevent any downtime of the system should
a minor failure occur.
Tag# Description Fuse type/size
FU-1 (120 VAC Model)
FU-1 (220 VAC Model)
FU-2
FU-2A
FU-2B
FU-3
FU-4
FU-5
FU-6
FU-13
FU-17
Main Power 120 VAC
Main Power 220/240 VAC
Empty
P-03
Empty
PS-2 Input Supply 120-240 VAC
PLC Input Supply 120-240 VAC
PS-1 Input Supply 120-240 VAC
PS-3 Input Supply 120-240 VAC
BPCV-01, BPCV-02
PS-1 Output 24VDC
Buss AGC-20 20A
Buss AGC-10 10A
None
Buss AGC-5 5A
None
Buss AGC-5 5A
Buss AGC-2 2A
Buss AGC-5 5A
Buss AGC-10 10A
Buss AGC-1 1A
Buss AGC-5 5A
Tag# Item Manufacturing/model
System:
P-01
P-02
P-03
FL-01
FL-02
PE-01/02/03
Recirculating Pump Motor
Recirculating Pump Head
Product Pump Motor
Product Pump Head
Product Pump Motor
Product Pump Head
Retentate flowmeter
Permeate flowmeter/Flow converter
Pressure sensors
Levitronix LPM-600.3-10
Levitronix DCP-600
MasterFlex® 77420-10 I/P peristaltic pump
MasterFlex®
MasterFlex® 77420-10 I/P peristaltic pump
MasterFlex®
Sonotec® FS04.210 CO.55/230 V2.0
Levitronix LFC-1C-PC
Repligen ACPM-799-01N
Panel:
HMI
PLC
PE-01 to PE-03
MCR-100
PS-1
PS-2
PS-3
PC-1
HMI/computer
PLC
Signal conditioner
PE-01/PE-02/PE-03
Master control relay
Ethernet switch
Power supply 48 VDC
Power supply 24 VDC
Power supply 12 VDC
Pump Controller
Allen-Bradley 6181P15C2MWX1AC Integrated
Panel Display Computer
Allen-Bradley 1766-L32BWA MicroLogix 1400
Allen-Bradley 931S-B1C6D-DC
Allen-Bradley 700-HF34Z24-4
N-Tron 104TX
Traco Power TSP600-148
MEAN WELL SDR-240-24
MEAN WELL MDR-20-12
Levitronix LPC 600.2-01
