1. Menu area
If you select menu, its content will be shown on the work area, or the sub area.
2. Tab area
Details about each menu appear.
3. Header area
The dialog box for switching to the user mode and administrator mode appears, and each mode's menu will be
displayed.
The link to help and dialog box for keyword search appears.
4. Help
Use Help to view or download Help file contents.
5. Display area
Displays the contents of the item selected in the menu area.
Machine information in the display area is not automatically updated. Click [Refresh] at the upper right in the
display area to update the machine information. Click the Web browser's [Refresh] button to refresh the entire
browser screen.
• When using a host name under Windows Server 2003/2003 R2/2008, or Windows Vista with
IPv6 protocol, perform host name resolution using an external DNS server. The host file cannot be
used.
Using Web Image Monitor
119
