IEEE802.1X Auth.(Ethernet)
Set the IEEE 802.1X authentication for Ethernet.
The default setting is [Inactive].
For details about IEEE 802.1X Authentication, see “Configuring IEEE 802.1X”.
Restr.IEEE802.1X Auth. Def.
You can return the IEEE 802.1X Authentication settings to their defaults.
LAN Type
When you have installed the wireless LAN interface board, select the method of connection.
The default setting is [Ethernet].
[LAN Type] is displayed when wireless LAN board is installed. If Ethernet and wireless LAN are both
connected, the selected interface has priority.
Ping Command
Check the network connection with ping command using given IPv4 address.
If you fail to connect to the network, check the following, and then retry the ping command.
• Make sure that "IPv4" in [Effective Protocol] is set to [Active].
• Check that the machine with assigned IPv4 address is connected to the network.
• There is a possibility that the same IPv4 address is used for the specified equipment.
Permit SNMPv3 Communictn.
Set the encrypted communication of SNMPv3.
The default setting is [Encryption/Cleartext].
If you select to [Encryption Only], you need to set an encryption password for the machine.
Permit SSL/TLS Comm.
Set the encrypted communication of SSL/TLS.
The default setting is [Ciphertext Priority].
If you set to [Ciphertext Only], you need to install the SSL certificate for the machine.
Host Name
Specify the host name.
Enter the host name using up to 63 characters.
Machine Name
Specify the machine name.
Enter the machine name using up to 31 characters.
• p.18 "Accessing User Tools"
Interface Settings
31
