Rear Side
• Do not pull out all the trays in the vacuum Feed LCIT RT5100 (when not linked to the main unit)
because it could fall over.
Main Board
1. Remove the rear right and left covers (page 8 "Rear Right Cover",page 8 "Rear Left Cover").
2. Main board ( x7, hook x1, all connectors and clamps)
Tray 1 Pickup Belt Motor
1. Remove the rear right and left covers (page 8 "Rear Right Cover",page 8 "Rear Left Cover").
2. Tray 1 grip motor bracket [A] ( x4, x2)
1. Replacement and Adjustment
48
