Ricoh LCIT RT5100 User Manual

Vertical Transport Exit Motor
1. Remove the rear right and left covers (page 8 "Rear Right Cover", page 8 "Rear Left Cover").
2. Vertical transport exit motor bracket [A] ( x3, x1)
3. Vertical transport exit motor [A] ( x2)
• Do not remove the damper [B] between the motor and the bracket. This damper is factory
installed and cannot be adjusted outside the factory.
1. Replacement and Adjustment
72
