T
echnical
B
ulletin PAGE: 1/2
Reissued: 09-Oct-09
Model:
Al-P1
Date:
23-May-08
No.:
RG179010b
RTB Reissue
The items in bold italics have been corrected or added.
Installation Procedure for the IPDS Option
When Used on the Model AL-P1
The IPDS option will be released in June 2008. The installation procedure for this option
on the Model AL-P1 is shown below.
IPDS OPTION
Accessories
Description Q’ty
1. IPDS Emulation SD Card ...................................................... 1
Important: Only one Slot 1 is available for SD cards that contain applications. If you want
to use more than one application, merge all applications into one SD card
(SP5873-001).
Installation
1. Make sure the following requirements have been met.
Requirements:
z The Hard Disk Drive Option Type 5000 must be installed.
z The following firmware versions must be installed:
Firmware Name Version Firmware Number
System V1.08 or later G1795740B
NCS V7.14 or later G1795742B
Websys V1.12 or later G1795743B
Printer V1.08 or later G1795746B
2. Turn OFF the main switch.
Subject:
IPDS Option Release
Prepared by:
K. Hamada
From:
2nd Tech Support Sec. Service Support Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other ( ) Tier 2
To Next Page
