1. Open the center cover.
2. If the media holding lever (front) is lowered, raise the lever.
3. Wipe off dirt on the pinch rollers by using a dry cloth, or paper towel, etc.
If necessary, wipe it off with a damp and tightly wrung cloth, and then wipe it with a dry cloth.
1. Pinch roller
4. Close the center cover.
• After cleaning, check that the pinch rollers are dry before setting media.
Cleaning the Media Sensors
Media sensors are located above the media feeding surface at the rear of the machine and on the
underside of the carriage. If dust builds up on the sensors on the underside of the carriage, it may not be
possible to correctly detect media. When dust builds up on the surface of the sensors, remove the dust
with a cotton swab.
2. Daily Care and Maintenance
30
