2.Replacement and Adjustment
23
Trimming Blade, Blade Cradle
Trimming Blade Cover
The trimming blade [A] cover protects the trimming blade
1. Remove the rear cover. (Rear Cover)
2. Remove the left upper cover. (Left Upper Cover)
3. Remove the top cover. (Top Cover)
4. Remove the trimming blade cover. ( x 5)
Trimming Blade
1. Remove the rear cover. (Rear Cover)
2. Remove the left upper cover. (Left Upper Cover)
3. Remove the top cover. (Top Cover)
4. Remove the trimming blade cover. (Trimming Blade Cover)
