2.Replacement and Adjustment
61
3. Lay the board on a flat, clean surface.
Voltage Regulator
1. Remove the rear cover. (Rear Cover)
The voltage regulator [A] is the board on the right side, covered by wire mesh.
2. Disconnect the board:
[A] Top ( x2)
[B] Bottom ( x1)
