Ricoh TR5050 - Motors; Cutter Motor; Feed Unit

2.Replacement and Adjustment
28
Motors
Cutter Motor
• Never attempt to remove the cutter motor [A]. Removing it is dangerous.
• If the cutter motor fails, the trimmer unit must be replaced.
Feed Unit
Feed Motor
1. Remove the feed unit. (Feed Unit)
2. Disconnect the feed motor harness [A]. ( x1)
