RIGOL Chapter 1 Quick Start
1-18 MSO1000Z/DS1000Z User’s Guide
Print
Press this key to print the screen or save the screen to a USB
storage device.
― If a PictBridge printer is connected currently and the printer is
in idle state, pressing this key will execute the print operation.
― If no printer is connected but a USB storage device is inserted,
pressing this key can save the screen to the USB storage
device in the specified format. For more details, please refer to
the introduction in "Storage Type".
― If both a printer and a USB storage device are connected at
the same time, the printer enjoys higher priority when
pressing this key.
Note: MSO1000Z/DS1000Z only supports the flash memory USB
storage device of FAT32 format.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
