RIGOL Chapter 18 Specifications
18-4 MSO1000Z/DS1000Z User’s Guide
Pulse Condition Positive Pulse Width (greater than, lower than, within specific
interval)
Negative Pulse Width (greater than, lower than, within specific
interval)
Pulse Width
8 ns to 10 s
Runt Trigger (Optional)
Pulse Width
Condition
None, >, <, <>
Pulse Polarity
Positive, Negative
Pulse Width
Range
8 ns to 10 s
Window Trigger (Optional)
Window Type Rising, Falling, Rising/Falling
Trigger Position
Enter, Exit, Time
Window Time 8 ns to 10 s
Nth Edge Trigger (Optional)
Edge Type Rising, Falling
Idle Time 16 ns to 10 s
Edge Number
1 to 65535
Slope Trigger
Slope Condition Positive Slope (greater than, lower than, within specific
interval)
Negative Slope (greater than, lower than, within specific
interval)
Time Setting
8 ns to 10 s
Video Trigger
Signal Standard NTSC, PAL/SECAM, 480P, 576P
Pattern Trigger
Pattern Setting H, L, X, Rising, Falling
Delay Trigger (Optional)
Edge Type Rising, Falling
Delay Type
>, <, <>, ><
Delay Time 8 ns to 10 s
TimeOut Trigger (Optional)
Edge Type Rising, Falling, Rising/Falling
Timeout time 16 ns to 10 s
Duration Trigger
Pattern H, L, X
Trigger Condition
>, <, <>
Duration Time
8 ns to 10 s
Setup/Hold Trigger (Optional)
Edge Type Rising, Falling
