2. Set the digital channels included in Group1
 Add digital channels
Turn the multi-function knob
to select any channel (the selecting state
label is ); press the knob or press Group1. At this point, the selecting
state label of the channel changes to
(denote the channel is assigned to
Group1).
 Delete digital channels
Turn the multi-function knob
to select any channel (the selecting state
label is ); press the knob or press Group1. At this point, the selecting
state label of the channel changes to
(denote the channel is removed
from Group1).
Note: You can add or delete digital channels repeatedly.
3. Cancel the grouping setting of the digital channel or user-defined
channel group
Press UnGroup to open the channel/group list; turn the multi-function knob
to select the desired digital channel or group and press this knob or UnGroup to
cancel the grouping setting of the digital channel or the channel group.
Note: The ungrouping operation can only be performed on digital channels or
user-defined channel groups that have been grouped. If no grouping setting is
performed, UnGroup is grayed out and disabled.
To Specify the Waveform Display Size
You can set the display size of the digital channel waveforms on the screen. The sizes
available are small, medium and large.
Press LA  WaveSize; turn the multi-function knob to select the desired
display size and press the knob. You can also press WaveSize continuously to
switch he current display size. The sizes available are S (small), M (medium) and L
(large).
