RIGOL Chapter 13 Store and Recall

13-10 MSO4000/DS4000 User’s Guide

Disk Management

Press Storage  Disk.Manage to open the disk management interface as shown

in the figure below. Turn the multi-function knob to select the desired disk (the

disk currently selected is displayed in green) and press the knob to open the disk

selected.

Execute the following operations through the disk management menu:

 To Select File Type

 To Create a New File or Folder

 To Delete a File or Folder

 To Rename a File or Folder

 To Clear the Local Memory
