RIGOL Chapter 12 Display Control
12-2 MSO4000/DS4000 User’s Guide
To Specify the Display Type
Press Display to open the display menu and press Type to set the waveform display
mode to “Vectors” or “Dots”.
 Vectors: the sample points are connected by lines and displayed. Normally, this
mode can provide the most vivid waveform to view the steep edge of the
waveform (such as square waveform).
 Dots: display the sample points directly. You can directly view each sample point
and use the cursor to measure the X and Y values of the sample point.
