RIGOL Chapter 16 Display Control
16-4 MSO7000/DS7000 User Guide
To Set the Grid Brightness
Press Brightness, then rotate the multifunction knob at a small step value or
use the pop-up numeric keypad to set the grid intensity. The default is 20%, and the
range available is from 1% to 100%.
Scale
Press Show Scale continuously to enable or disable the scale display on the screen.
By default, it is set to "OFF".
Note: When the digital channel is enabled, the scale in the vertical direction is
hidden automatically.
Color Grade
Press More → Color Grade to enable or disable the color grade display of the
analog channel waveforms on the screen. By default, it is set to "OFF". When
enabled, different colors are displayed on the screen to indicate the times of data
acquisition or acquisition probability.
Waveform Freeze
Press More → Waveform Freeze to enable or disable waveform freeze function. If
enabled, when you press the RUN/STOP key, the current waveform display
(including the history waveforms) will be frozen. If disabled, when you press the
RUN/STOP key, only the last acquired waveform will be displayed.
