⚫ Click the close button at the upper-right corner of the message box to
close the prompt window.
⚫ Click other windows on the touch screen and operate on the windows.
⚫ Double-click the left mouse button to stop the recording/playing of the
waveforms or stop the self-calibration.
Drag Operation
Click to select the menu and then drag the mouse to change the position of the
waveforms or the cursor on the screen.
Scroll Operation
For the menu with the icon on it, click to select the parameter item, then
scroll up and down with the mouse to adjust the parameter value. You can also
set it with the pop-up numeric keypad.
For the menu with the icon , click the menu and scroll up and down with the
mouse to adjust the parameter.
For example, to adjust the waveform brightness, first click on the function
navigation icon to open the function navigation. Then click on the
"Display" icon to enter the "Display" setting menu. Click Intensity to
adjust the intensity. The adjustable range of the intensity is from 1% to 100%.
Scroll up with the mouse to increase the brightness, and scroll down with the
mouse to decrease the brightness.
Rectangle Drawing
Click the function navigation icon at the lower-left corner of the externally
connected screen to open the function navigation. Then click on the "Draw
rect" icon to switch to the rectangle drawing mode. Drag the mouse cursor
from upper left to lower right across the screen to draw a rectangle on the
screen, and then a menu is displayed on the screen. At this time, you can click
to select "Trigger zone A", "Trigger zone B", "Histogram", "Horizontal zoom in",
"Vertical zoom in", or "Waveform zoom in". Drag the mouse cursor from lower
right to upper left across the screen to draw a rectangle on the screen. Move
your cursor away from the screen, and then a menu is displayed on the screen.
At this time, you can click to select "Trigger zone A", "Trigger zone B",
"Histogram", "Horizontal zoom out", "Vertical zoom out", or "Waveform zoom
out".
