RIGOL Chapter 14 Waveform Recording & Playing
14-4 DS8000-R User Guide
Horizontal Direction. Therefore, the maximum number of frames of waveform
recording is also related to the "Sample Rate" and "Horizontal Time Base". This
oscilloscope provides ceaseless recording for a maximum of 450,000 frames of
real-time waveforms.
4. Beeper
Click Beeper continuously to set whether the beeper sounds when the
recording is completed.
âš« : the beeper sounds at the end of recording.
âš« : the beeper does not sound at the end of recording.
Play Options
Waveform playing function can play back the waveforms currently recorded. Before
playing back the waveforms, you can click More → Setting to select "Play" to set
the following parameters.
1. Play Mode
Click Mode continuously to set the playback mode to (cycle) or
(single).
âš« : plays back repeatedly until you stop it manually.
âš« : plays for a single time, and then stops automatically.
2. Playback Sequence
Click Sequence continuously to select the playback sequence to (playback
clockwise) or (playback counterclockwise).
âš« : plays from the start frame to the end frame.
âš« : plays from the end frame to the start frame.
3. Playback Interval
The playback interval indicates the time interval between the frames during the
playing process.
Click Interval, then use pop-up numeric keypad or scroll with the mouse to set
the time interval between frames. The available range is from 5 ms to 10 s.
4. Start Frame
Click Start Frame, then use pop-up numeric keypad or scroll with the mouse to
set the start frame for playing back the waveforms.
5. End Frame
Click End Frame, then use pop-up numeric keypad or scroll with the mouse to
set the end frame for playing back the waveforms.
