Rigol MSO7000 Series User Programming Manual

Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-85
:LAN:AUToip
Syntax
:LAN:AUToip <bool>
:LAN:AUToip?
Description
Turns on or off the Auto IP configuration mode; or queries the on/off status of the
current Auto IP configuration mode.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
1|ON
Remarks
When the auto IP mode is valid, disable DHCP manually. You can self-define the
gateway and DNS address for the oscilloscope.
Return
Format
The query returns 1 or 0.
Example
:LAN:AUToip OFF /*Disables the Auto IP configuration mode.*/
:LAN:AUToip? /*The query returns 0.*/
:LAN:GATeway
Syntax
:LAN:GATeway <string>
:LAN:GATeway?
Description
Sets or queries the default gateway.
Parameter
Name
Type
Range
Default
<string>
ASCII String
Refer to Remarks
——
Remarks
 The format of <string> is nnn,nnn,nnn,nnn. The range of the first section of
"nnn" is from 0 to 223 (except 127), and the ranges of the other three sections of
"nnn" are from 0 to 255.
 When you use this command, the IP configuration mode should be Auto IP or
Static IP mode.
Return
Format
The query returns the current gateway in strings.
Example
:LAN:GATeway 192.168.1.1 /*Sets the default gateway to 192.168.1.1.*/
:LAN:GATeway? /*The query returns the current gateway.*/
:LAN:DNS
Syntax
:LAN:DNS <string>
:LAN:DNS?
Description
Sets or queries the DNS address.
Parameter
Name
Type
Range
Default
<string>
ASCII String
Refer to Remarks
——
Remarks
 The format of <string> is nnn,nnn,nnn,nnn. The range of the first section of
"nnn" is from 0 to 223 (except 127), and the ranges of the other three sections of
"nnn" are from 0 to 255.
 When you use this command, the IP configuration mode should be Auto IP or
Static IP mode.

Rigol MSO7000 Series Specifications

General

Memory Depth	Up to 500 Mpts
Operating Temperature	0 °C to +50 °C
Channels	4 analog + 16 digital
Display	10.1 inch capacitive touchscreen
Waveform Capture Rate	Up to 600, 000 wfms/s
Vertical Resolution	8 bits
Maximum Input Voltage	400 V (DC + AC peak)
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Window, Runt, Setup/Hold, Delay, Nth Edge
Protocol Decoding	RS232/UART, I2C, SPI, CAN, LIN, FlexRay, I2S, MIL-STD-1553, ARINC429
Interfaces	USB, LAN, HDMI
