CIP services
Chapter 1
Rockwell Automation Publication 1756-PM020F-EN-P - January 2019 31
4th Message Reply Field Bytes (in hex) Description - Symbolic Segment Addressing
Reply Service D3 Write Tag Fragmented Service (Reply)
Reserved 00
General Status 00 Success
Extended Status Size 00 No extended status
See also
CIP Services and User-created Tags on page 41
Writing 1750 SINTs to the tag TotalCount using Symbol Instance
Addressing would consist of the following four service requests with
service data as shown in the tables.
1st Message Request Field Bytes (in hex) Description - Symbol Instance Addressing
Request Service 53 Write Tag Fragmented Service (Request)
Request Path Size 03 Request Path is 3 words (6 bytes) long
Request Path 20 6B
25 00 1A E0
Logical Segment for Symbol Class ID
Logical Segment for Instance ID for the tag TotalCount
Request Data C2 00 SINT Tag Type Value
D6 06 Number of elements to write (1750)
00 00 00 00 Start at this Offset
nn,nn,...nn Element Data for Elements 0 through 473
1st Message Reply Field Bytes (in hex) Description - Symbol Instance Addressing
Reply Service D3 Write Tag Fragmented Service (Reply)
Reserved 00
General Status 00 Success
Extended Status Size 00 No extended status
2nd Message Request Field Bytes (in hex) Description - Symbol Instance Addressing
Request Service 53 Write Tag Fragmented Service (Request)
Request Path Size 03 Request Path is 3 words (6 bytes) long
Request Path 20 6B
25 00 1A E0
Logical Segments for Symbol Class ID
Logical Segment for Instance ID for the tag TotalCount
Request Data C2 00 Tag Data Type
D6 06 Number of elements to write (1750)
EC 01 00 00 Start at this Offser
nn,nn,...nn Element Data (474 through 947)
Example Using Symbol Instance
Addressing
