10 Rockwell Automation Publication 7000-IN008D-EN-P - August 2019
Chapter 1 Receiving and Storing Procedures
• Keep the drive bolted to the wooden shipping skid to minimize the
possibility of it tipping. Do not remove the wood skid and top lifting angle
until the drive is at the installation area. If the drive is crated, the crate
includes a pair of lifting angles. Reinstall both lifting angles on top of drive.
High-power air-cooled drives and converter sections do not have wood
skids or top lifting angles but have permanently-attached steel frame bases.
Shipping Details
Receiving the Drive
When your drive arrives, remove the packing and check for damage that can
occur during shipping. Report any damage immediately to your carrier’s claims
office as soon as possible after receiving the drive. Rockwell Automation offers
reasonable assistance to resolve damage claims.
Each MV variable speed drive has a shock indicator installed on the outside of the
converter cabinet. The shock indicator shows black in the chevron shaped area if
the drive experienced sufficient shock during transit.
Product
Type
VFD Frame
Type
System Voltage (VFD Shipping Pieces) Packaging Type Truck Type Off-loading Options
Forklift Overhead Lifting
2300V 3300V 4160V 6600V Domestic Export Enclosed
Trailer
Flatbed Single Tande
m
Top
Provisions
Bottom
Provisions
Air-
cooled
VFD
‘A’ Frame One One One One Yes Yes Yes Yes Yes n/a Yes n/a
‘B’ Frame
with
heat sink
One One One One Yes Yes Yes Ye s Yes n /a Yes n/ a
‘B’ Frame
with
heat pipe
n/a Two Two Two or
Three
(1)
Yes Yes n/a Yes One for
CMC
cabinet
and Line
Reactor
(3)
Yes One for
CMC
cabinet
and Line
Reactor
(3)
Yes
Liquid-
cooled
VFD
‘C’ Frame n/a n/a One One or
Two
(2)
Yes Yes n/a Yes One for
CMC
cabinet
and Line
Reactor
(4)
Yes Yes n/ a
(1) 4160V RPTX and 4160V RPDTD have two shipping pieces; 6600V RPTX has two shipping pieces; 6600V RPDTD has three shipping pieces.
(2) 6600V RPDTD (430A and higher) has two shipping pieces; balance of liquid-cooled offering ships as single piece.
(3) CMC cabinet and Line Reactor only have provisions for overhead lifting and/or forklift.
(4) Can use single forklift for CMC cabinet or Line Reactor (for configurations where it ships separately)
