Publication 1783-UM002C-EN-P - April 2009 47
Chapter 2
Install or Remove the
CompactFlash Card
Follow this procedure to install or remove the CompactFlash card.
Install or remove the CompactFlash card by grasping the tab on the card and
either inserting it or removing it from the slot at the bottom of the switch.
WARNING
When you insert or remove the CompactFlash Card while power
is on, an electrical arc can occur. This could cause an explosion
in hazardous location installations. Be sure that power is
removed or the area is nonhazardous before proceeding.
IMPORTANT
You can install and remove the CompactFlash card while the
switch is powered. However, If you do not have a CompactFlash
card installed in the switch, you will be unable to do the
following:
• start the Device Manager web interface when you apply power to
the switch
• save configuration changes you made with the AOP via RSLogix
5000 software
• boot up the switch (the POST will not begin)
VRTA A
31792-M
