Rockwell Automation STRATIX 8000 1783-MS06T User Manual

Publication 1783-UM002C-EN-P - April 2009 57
Chapter 2
Use the Command-Line Interface
You can manage the switch from the command-line interface (CLI) by
connecting your personal computer directly to the switch console port or
through the network by using Telnet. This procedure explains how to access
the CLI through the console port.
1. Connect the supplied RJ45-to-DB-9 adapter cable to the standard 9-pin
serial port on the personal computer.
2. Connect the other end of the cable to the console port on the switch.
3. Start a terminal-emulation program on the personal computer.
4. Configure the personal computer terminal emulation software for 9600
bits per second, 8 data bits, no parity, 1 stop bit, and no flow control.
5. Use the CLI to enter commands to configure the switch.
See the Cisco Switch Command Reference Manual, available at
http://www.cisco.com
for more information.
Use SNMP Management Applications
You can use SNMP management applications such as IntraVue by Network
Vision or HP OpenView to configure and manage the switch.
WARNING
The console port is intended for temporary local programming
purposes only and not intended for permanent connection. If
you connect or disconnect the console cable with power
applied to this module or the programming device on the other
end of the cable, an electrical arc can occur. This could cause
an explosion in hazardous location installations. Be sure that
power is removed or the area is nonhazardous before
proceeding.
