21
AT-80SL
EXPLODED VIEW PARTS LIST(Fig.1)
Fig.1-1
Rear
Bottom
1 72561067 LID ASSY 1
NOTE: ‘LIDASSY’ includes the following parts. (Fig.1, Fig1-1, Rear and Bottom)
No. PART CODE PART NAME DESCRIPTION Q’TY
1-1 72561090 LID SHAFT ASSY 1
1-2 ******** REAR LID CB 1
1-3 ******** CENTER LID CB 1
1-4 ******** FRONT LID CB 1
1-10 02568034 HINGE 55-U2529 4
1-11 02898867 LID KNOB GOLD 2
1-12 03455912 LID CUSHION E 2
1-13 03455901 LID CUSHION D 2
1-14 03455890 LID CUSHION C 2
1-15 03455889 LID CUSHION B 2
1-16 02675812 LID CUSHION A 2
No. PART CODE PART NAME DESCRIPTION Q’TY
1-5 02235656 HINGE HOLDER 6
1-6 00787256 HINGE B 4
1-7 72347312 LID BOARD STOPPER 2
1-8 03128378 HINGE HOLDER R 1
1-9 03128367 HINGE HOLDER L 1
No. PART CODE PART NAME DESCRIPTION Q’TY
m 40232078 SCREW M4X20 FLAT ZC 2
No. PART CODE PART NAME DESCRIPTION Q’TY
p 40011101 SCREW 3X8 BINDING TAPTITE B BZC 30
n 40347467 SCREW 3.5X8 BINDING TAPPING TWIN BZC 60
To Next Page
