11
FANTOM-X6
EXPLODED VIEW PARTS LIST
[PARTS]
[SCREWS]
No
PART CODE CATEGORY Part name Description Q'TY
1 03565245 CASING DISPLAY ESCT 1
2 03560889 DISPLAY UNIT LCD KCG057QV1DB-G00 1
3 03562134 CASING TOP PANEL 1
4 72564256 PWB ASSY PANEL-A KEYTOP ASSY 1
5 03562123 CHASSIS DISPLAY HOLDER 1
6 72564278 PWB ASSY PANEL-B KEYTOP ASSY 1
7 72564334 PWB ASSY PANEL-C KEYTOP ASSY 1
8 72564212 PWB ASSY INVERTER BOARD ASSY 1
9 03567789 MISCELLANEOUS INSULATING SHEET 1
10 72564323 PWB ASSY JACK BOARD ASSY 1
11 72564734 PWB ASSY MAIN BOARD ASSY 1
NOTE:When you replace the MAIN BOARD ASSY for repairng, be sure to perform the
"MAIN BOARD SETTING FOR SELECTING MODEL PROCEDURE"(to see P24).
In addition, we supply the MAIN BOARD ASSY of FANTOM-X6 setting for spare parts.
12 72564245 PWB ASSY PC CARD BOARD ASSY 1
13 72564312 PWB ASSY INLET BOARD ASSY 1
14 01785823 POWER SUPPLY UNIT SWITCHING REGULATOR A1DU2L3B034 1
15 03125845 CHASSIS PWR SPLY HOLDER 1
16 03126556 CASING END BLOCK 1
17 02674034 CHASSIS PANEL HOLDER 2
18 72568667 KEYBOARD ASSY KEYBOARD ASSY SK-961-L 1
19 03126567 CASING BENDER PANEL 1
20 03234723 BENDER UNIT BENDER PB-H0204 1
21 03122045 CASING SIDE COVER R 1
22 03125812 CHASSIS SIDE HOLDER R 1
23 72235056 CASING BOTTOM COVER ASSY UNIT 1
24 03670689 MISCELLANEOUS CUSHION A 1
25 03670701 MISCELLANEOUS CUSHION B 1
26 03125801 CHASSIS SIDE HOLDER L 1
27 03122034 CASING SIDE COVER L 1
28 03017778 CASING EXP COVER 1
29 12359139 MISCELLANEOUS RUBBER FOOT FF-018 BLK 4
30 72235090 PWB ASSY EXP BASE BOARD ASSY 1
31 72564223 PWB ASSY LCD BOARD ASSY 1
32 03670734 MISCELLANEOUS SPACER M3X20 HEX 1
33 03562112 CASING DISPLAY COVER 1
34 03567790 CASING DISPLAY CUSHION 4
35 03017867 MISCELLANEOUS CARD SPACER MPS-10-0 2
36 40120967 MISCELLANEOUS COATING CLIP CS-3 1
37 03122067 CASING RUBBER SW ESCT 1
38 03562145 KNOB,BUTTON RUBBER SW 1
39 03128767 PICK UP,SENSOR PRESSURE SENSOR SHEET 1
40 03670712 MISCELLANEOUS CUSHION C 1
41 02673945 MISCELLANEOUS STAY BENDER 1
42 01455523 MISCELLANEOUS CORD BUSHING EDS-1717U 1
No PART CODE Part name Description Q'TY
a 40011312 SCREW 3X8 BINDING TAPTITE P BZC 23
b 40011101 SCREW 3X8 BINDING TAPTITE B BZC 18
c 40011056 SCREW 3X6 BINDING TAPTITE B ZC 57
d 40017934 SCREW M3X6 PAN MACHINE W/SW+PW FE ZC 4
e 40011490 SCREW M3X6 PAN MACHINE W/SW BZC 22
f 40011123 SCREW 4X8 BINDING TAPTITE B BZC 6
g 40010345 SCREW M4X10 BINDING MACHINE FE BZC 1
h 40013078 SCREW M3X10 PAN MACHINE W/SW FE ZC 1
i 40454045 SCREW 3X8 FLAT TAPTITEB NI FLANGE SOCKET 8
j 40012501 SCREW M4X12 BINDING TAPTITE P FE BZC 1
k 40011067 SCREW 3X8 BINDING TAPTITE B FE ZC 16
l 22150501 STAND OFF M3 L10C 4
