6
Mar.2004
LOCATION OF CONTROLS PARTS LIST
[TOP]
[REAR]
NO
PART CODE CATEGORY PART NAME DESCRIPTION Q’TY
1 03562134 CASING TOP PANEL 1
2 03562112 CASING DISPLAY COVER 1
2 03560889 DISPLAY UNIT LCD KCG057QV1DB-G00 1
2 03565245 CASING DISPLAY ESCT
3 03565234 KNOB,BUTTON J R-KNOB SF-ELA BLK/SLV 2
3 03126167 POTENTIOMETER 12M/M ROTARY POTENTIOMETER EVJY10FB6A24 2
4 03565234 KNOB,BUTTON J R-KNOB SF-ELA BLK/SLV 4
4 03126178 POTENTIOMETER 9M/M ROTARY POTENTIOMETER EVUF2JFK3B14 4
5 22485303 KNOB,BUTTON D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
5 01905467 ENCODER ROTARY ENCODER EVE GC1 F20 24B 1
6 01343089 CASING ESCUTCHEON D-BEAM CONTROLLER ESCT BLK 1
7 01900612 DIODE DIODE TPS611 1
7 12169368 MISCELLANEOUS LED SPACER LDS-40B 1
8 03126134 DIODE LED TLN233 1
8 02230578 MISCELLANEOUS LED SPACER LDS-50R 1
9 03120890 KNOB,BUTTON D S-KEYTOP SX1H-B GRS 18
9 02125167 DIODE LED (YELOW) SLI-343DCT32W 18
9 01340290 SWITCH TACT SWITCH EVQ11A H=5.0 18
10 01011656 DIODE LED (RED) SLR-332VR3F 5
10 12169406 MISCELLANEOUS LED SPACER 5
11 03120890 KNOB,BUTTON D S-KEYTOP SX1H-B GRS 1
11 03122112 DIODE LED(BLUE) SLR-343BBT3F 1
11 01340290 SWITCH TACT SWITCH EVQ11A H=5.0 1
12 03120890 KNOB,BUTTON D S-KEYTOP SX1H-B GRS 9
12 01340290 SWITCH TACT SWITCH EVQ11A H=5.0 9
13 03120889 KNOB,BUTTON D S-KEYTOP SX2H-B GRS 7
13 01340290 SWITCH TACT SWITCH EVQ11A H=5.0 14
14 03565190 KNOB,BUTTON KEYTOP STOP 1
14 00894645 SWITCH TACT SWITCH SKECAF WITHOUT LED 1
15 00894645 SWITCH TACT SWITCH SKECAF WITHOUT LED 1
15 03565212 KNOB,BUTTON KEYTOP PLAY 1
16 00894645 SWITCH TACT SWITCH SKECAF WITHOUT LED 1
16 03565223 KNOB,BUTTON KEYTOP REC 1
17 01012078 DIODE LED (GREEN) SLR-332MG3F 1
17 12169406 MISCELLANEOUS LED SPACER 1
18 01783923 KNOB,BUTTON N S-KEYTOP MD1H 5
18 02894090 DIODE LED (ORNG) SLR-343DUT32 5
19 01455901 MISCELLANEOUS LED SPACER LH-36-9 1
19 00127367 DIODE LED (RED/GREEN) SPR-39MVW 1
20 03562256 POTENTIOMETER ROTARY POTENTIOMETER EVUF2AE20B14 1
21 03234723 POWER SUPPLY UNIT BENDER PB-H0204 1
22 01234090 KNOB,BUTTON D T-KEYTOP MX4B BLK 1
22 01340290 SWITCH TACT SWITCH EVQ11A H=5.0 4
23 02013090 KNOB,BUTTON F C-KEYTOP MX1H CLR 1
23 03122112 DIODE LED(BLUE) SLR-343BBT3F 1
23 01340290 SWITCH TACT SWITCH EVQ11A H=5.0 1
24 03562145 KNOB,BUTTON RUBBER SW 1
24 03122067 CASING RUBBER SW ESCT 1
24 03128767 PICK UP,SENSOR PRESSURE SENSOR SHEET 1
NO PART CODE CATEGORY PART NAME DESCRIPTION Q’TY
25 72235056 CASING BOTTOM COVER ASSY 1
26 32490595 KNOB,BUTTON P S-KEY MX BLK 1
26 ******** SWITCH PUSH SWITCH 1
27 ******** AC INLET, OUTLET AC INLET 1
When you order the above parts, please order the 72564312 INLET BOARD ASSY.
28 03562156 CASING PC CARD ESCUTCHEON BLK 1
28 02900867 JACK,EXT TERMINAL CARD EJECTOR SCAB1A5600 1
29 02781189 JACK,EXT TERMINAL USB CONNECTOR YKF45-0021 1
30 13449275 JACK,EXT TERMINAL 6.5MM JACK YKB21-5074 2
31 13429274 JACK,EXT TERMINAL MIDI SOCKET YKF51-5041 1
32 03231812 JACK,EXT TERMINAL RCA(PIN) YKC21-4173 1
33 13449283 JACK,EXT TERMINAL 6.5MM JACK HLJ7101-01-3010 4
34 13449258 JACK,EXT TERMINAL 6.5MM JACK HLJ4306-01-3080 1
35 13449284 JACK,EXT TERMINAL 6.5MM JACK HLJ7001-01-3010 2
To Next Page
