WIRING DIAGRAM
fig.wiring-x6
CN9
CN1
CN22
CN18
CN13CN3 CN7
CN501
CN5 CN2
CN5 CN6
CN4 CN5
CN1 CN8
CN2 CN18
CN304
CN305
CN404
CN1
CN601
CN10 CN11
CN6
CN201
CN102
CN20
CN403
CN21
CN2
CN10
JACK BOARD
KEYBOARD UNIT
PC CARD
BOARD
LCD
BOARD
POWER
SWITCH
INVERTER
BOARD
INLET
BOARD
BENDER
MAIN BOARD
EXPANSION
BOARD
PANEL A
BOARD
PANEL B
BOARD
PANEL C
BOARD
LCD
D 2PIN
A 2PIN
B 7PIN
C 2PIN
E 20PIN
H 50PIN
I 18PIN
O 4PIN
J 15PIN
F 34PIN
G 34PIN
K 38PIN
L 12PIN
M 10PIN
N 40PIN
Q 18PIN P 16PIN
R
NO
PART CODE PART NAME DESCRIPTION
A. 03120801 WIRING W3
B. 02679390 WIRING 7X150-P2.5-XHP-XHP-F
C. 03564990 WIRING W3
D. 03564912 WIRING W1
E. 03565267 BAN CARD BNCD-P=0.50-K-20-320
F. 03129323 BAN CARD BNCD-P=1.00-K-34-60
G. 03129323 BAN CARD BNCD-P=1.00-K-34-60
H. 03565290 BAN CARD BNCD-S-P=0.50-K-50-140
I. 03566590 BAN CARD BNCD-P=1.00-K-18-500
J. 03564945 WIRING W2
K. 03129290 BAN CARD BNCD-P=1.00-K-38-400
L. 02344023 WIRING 12X200-P2.0-PHR-PHR-F
M. 03129301 BAN CARD BNCD-P=1.00-K-10-400
N. 03129312 BAN CARD BNCD-P=1.00-K-40-700
O. 02342012 WIRING 4X200-P2.0-PHR-PHR-F
P. 02128934 BAN CARD BNCD-P=1.25-K-16-320
Q. 03129334 BAN CARD BNCD-P=1.25-K-18-380
R. This wiring is included the LCD UNIT.
NO PART CODE PART NAME DESCRIPTION
