177
Effects List
Specifications for each Speaker Type
The speaker column indicates the diameter of each speaker unit (in
inches) and the number of units.
Flattens out high levels and boosts low levels, smoothing out
fluctuations in volume.
fig.MFX-40
Compresses signals that exceed a specified volume level, preventing
distortion from occurring.
fig.MFX-41
Cuts the reverb’s delay according to the volume of the sound sent into
the effect. Use this when you want to create an artificial-sounding
decrease in the reverb’s decay.
fig.MFX-42
Type
Cabinet Speaker Mic
SMALL 1
small open-back enclosure
10 dynamic
SMALL 2
small open-back enclosure
10 dynamic
MIDDLE
open back enclosure
12 x 1 dynamic
JC-120
open back enclosure
12 x 2 dynamic
BUILT-IN 1
open back enclosure
12 x 2 dynamic
BUILT-IN 2
open back enclosure
12 x 2 condenser
BUILT-IN 3
open back enclosure
12 x 2 condenser
BUILT-IN 4
open back enclosure
12 x 2 condenser
BUILT-IN 5
open back enclosure
12 x 2 condenser
BG STACK 1
sealed enclosure
12 x 2 condenser
BG STACK 2
large sealed enclosure
12 x 2 condenser
MS STACK 1
large sealed enclosure
12 x 4 condenser
MS STACK 2
large sealed enclosure
12 x 4 condenser
METAL STACK
large double stack
12 x 4 condenser
2-STACK
large double stack
12 x 4 condenser
3-STACK
large triple stack
12 x 4 condenser
40:
COMPRESSOR
Parameter
Value Explanation
Attack #
0–127
Sets the time from when the input exceeds
the Threshold until the volume starts being
compressed
Threshold #
0–127
Adjusts the volume at which compression
begins
Post Gain
0–+18 dB
Adjusts the output gain.
Low Gain
-15–+15 dB
Gain of the low frequency range
High Gain
-15–+15 dB
Gain of the high frequency range
Level #
0–127
Output level
L in
R in
L out
R out
Compressor
2-Band EQ
2-Band EQ
Compressor
41:
LIMITER
Parameter
Value Explanation
Release #
0–127
Adjusts the time after the signal volume falls
below the Threshold Level until compression
is no longer applied.
Threshold #
0–127
Adjusts the volume at which compression
begins
Ratio
1.5:1, 2:1,
4:1, 100:1
Compression ratio
Post Gain
0–+18 dB Adjusts the output gain.
Low Gain
-15–+15 dB Gain of the low frequency range
High Gain
-15–+15 dB Gain of the high frequency range
Level #
0–127 Output level
42:
GATE
Parameter
Value Explanation
Threshold #
0–127
Volume level at which the gate begins to close
Mode
GATE,
DUCK
Type of gate
GATE:
The gate will close when the
volume of the original sound decreases,
cutting the original sound.
DUCK (Ducking):
The gate will close when
the volume of the original sound
increases, cutting the original sound.
Attack
0–127
Adjusts the time it takes for the gate to fully
open after being triggered.
Hold
0–127
Adjusts the time it takes for the gate to start
closing after the source sound falls beneath
the Threshold.
Release
0–127
Adjusts the time it takes the gate to fully
close after the hold time.
Balance #
D100:0W–
D0:100W
Volume balance between the direct sound
(D) and the effect sound (W)
Level
0–127
Output level
L in
R in
L out
R out
Limiter
2-Band EQ
2-Band EQ
Limiter
L in
R in
L out
R out
Gate
Gate
JUNO-STAGE_e.book 177 ページ 2008年10月17日 金曜日 午後12時27分
