Roland OCTAPAD SPD-30 User Manual

11
Mar. 2010 SPD-30
Plain View (2) Parts List
View 3
View 4
View 5
No. Part Code Part Name Description Q’ty
e 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 31
f 40011334 SCREW 3X12 BINDING TAPTITE P FE BZC 7
g 40011056 SCREW 3X6 BINDING TAPTITE B ZC 2
No. Part Code Part Name Description Q’ty
e 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 4
g 40011056 SCREW 3X6 BINDING TAPTITE B ZC 6
No. Part Code Part Name Description Q’ty
a 40459534 SCREW M3X10 PAN MACHINE W/SW+PW BZC 1
e 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 2

Roland OCTAPAD SPD-30 Specifications

General

Product color	Black, Grey
Sound effects	Yes
Number of pads	8
Drum kits quantity	50
Instrument sounds quantity	670
Display type	LCD
Display resolution	160 x 160 pixels
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	6.3 mm
6.35 mm (1⁄4-inch) input	5
6.35 mm (1⁄4-inch) output	2
Power source type	AC

Weight and Dimensions

Depth	272 mm
Width	541 mm
Height	88 mm
Weight	3800 g
