7
Mar. 2010 SPD-30
Exploded View Parts List
No. Part Code Part Name Description Q’ty
1 5100009446 ZN R-KNOB MF-ELA BLK 2
2 5100009445 ZN R-KNOB MF-ELA ENC BLK 3
3 5100009458 PANEL SHEET 1
4 5100010681 TOP CASE ASSY 1
* This unit includes the following parts.
******** TOP CASE TOP CASE 1
******** PAD ASSY PAD ASSY (including sensors) 8
5 5100014741 SENSOR ASSY 1
6 5100011185 ADHESIVE TAPE #501L W5MM 50M -
7 5100009444 LED LENS 8
8 5100009456 SPRING 8
5100009635 LED SHEET ASSY 1
* This unit includes the following parts.
9A ******** LED-A BOARD ASSY 1
9B ******** LED-B BOARD ASSY 1
9C ******** LED-C BOARD ASSY 1
9D ******** LED-D BOARD ASSY 1
10 5100009465 SHIELD SHEET 1
11 5100009464 DISPLAY CUSHION 4
12 5100009530 LCD CMF2P0399-E 1
13 5100009449 RUBBER SW A 1
14 5100009451 RUBBER SW B 1
15 5100013049 LED CUSHION 1
16 5100010763 DUST COVER 2
17 5100009453 JACK BOARD HOLDER 1
18 5100009627 JACK BOARD ASSY 1
19 5100009631 PANEL BOARD ASSY 1
20 40122556 DOUBLE FACED ADHESIVE TAPE #575X W30MM 30M 10P 30CM -
21 5100009623 MAIN BOARD ASSY 1
22 5100011928 GASKET 3X10X10 1
23 5100009452 MAIN BOARD HOLDER 1
24 5100009443 BOTTOM CASE 1
25 5100000903 CORD HOOK 2
26 5100012055 FOOT 4
27 5100009459 REAR PANEL SHEET A 1
28 5100009460 REAR PANEL SHEET B 1

Roland OCTAPAD SPD-30 Specifications

General

Product color	Black, Grey
Sound effects	Yes
Number of pads	8
Drum kits quantity	50
Instrument sounds quantity	670
Display type	LCD
Display resolution	160 x 160 pixels
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	6.3 mm
6.35 mm (1⁄4-inch) input	5
6.35 mm (1⁄4-inch) output	2
Power source type	AC

Weight and Dimensions

Depth	272 mm
Width	541 mm
Height	88 mm
Weight	3800 g
