Mar. 2010 SPD-30
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
# 5100010681 TOP CASE ASSY 1
# 5100009443 BOTTOM CASE 1
CHASSIS
# 5100009452 MAIN BOARD HOLDER 1
# 5100009453 JACK BOARD HOLDER 1
KNOB, BUTTON
# 5100009445 ZN R-KNOB MF-ELA ENC BLK 3
# 5100009446 ZN R-KNOB MF-ELA BLK 2
# 5100009449 RUBBER SW A 1
# 5100009451 RUBBER SW B 1
JACK, EXT TERMINAL
00569278 6.5MM JACK LGR4609-7100F 10
13429676 MIDI CONNECTOR YKF51-5048V (TWIN) 1
13449711 AC ADAPTOR JACK HEC0470-01-630 1
04907401 USB CONNECTOR A TYPE FEMALE UAR80-4K5J00 1
# 5100009531 USB CONNECTOR B TYPE FEMALE YKF45-0044N 1
DISPLAY UNIT
# 5100009530 LCD CMF2P0399-E 1
PWB ASSY
# 5100009623 MAIN BOARD ASSY 1
# 5100009631 PANEL BOARD ASSY 1
# 5100009627 JACK BOARD ASSY 1
# 5100009635 LED SHEET ASSY 1
* This unit includes the following parts.
# ******** LED-A BOARD ASSY 1
# ******** LED-B BOARD ASSY 1
# ******** LED-C BOARD ASSY 1
# ******** LED-D BOARD ASSY 1
DIODE
03459534 LED (RED) TLSU1002A(TO2) MUTE, FX CTRL, ERASE,
SET LOPP/NEXT, REC,
STANDBY, KIT>, KIT<,
Pads x 8
16
# 5100009027 LED SMLE12EC6TT86 PLAY 1
# 5100009028 LED SML-212U2TT86A PHRASE LOOP 2
# 5100010910 LED SMLE12BC7TT86 V-LINK 1
POTENTIOMETER
02671212 ROTARY ENCODER EVE GB1 F15 24B Functions x 3 3
02891812 12M/M ROTARY POTENTIOMETER RK12L12C0C08 MASTER, PHONES 2
WIRING, CABLE
# 5100009524 WIRING W1 1
# 5100009525 WIRING W3 2
# 5100009526 WIRING W4 2
# 5100009519 WIRING A-1.0-40X170-4(8)X4(8)-.7X.05 2
PICK UP, SENSOR
# 5100014741 SENSOR ASSY 1
