40
System Compressor Parameters
Parameter Value Explanation
Compressor
Switch
OFF, ON Turns the compressor on/o .
Type
When you change this parameter, the Compressor
parameters will be automatically adjusted to the optimal
values.
You can make the settings easily by rst setting the
Compressor Type and then changing only the necessary
parameters.
HARD COMP Applies strong compression.
SOFT COMP Applies mild compression.
LOW BOOST Boosts the low end.
MID BOOST Boosts the midrange.
HI BOOST Boosts the high end.
USER The saved settings are written.
Split Freq Low
40, 50, 63, 80,
100, 125, 160,
200, 250, 315,
400, 500, 630,
800 [Hz]
Sets the frequency separating the
low-frequency range (LOW) and
midrange (MID).
Split Freq High
400, 500, 630,
800, 1000, 1250,
1600, 2000, 2500,
3150, 4000, 5000,
6300, 8000 [Hz]
Sets the frequency separating the
high-frequency range (HIGH) and
midrange (MID).
Common to Low, Mid, and High
Parameter Value Explanation
Level
0–24 [dB]
(1 dB Step)
Output Level
Attack Time 0–100
Sets the time it takes until the level is
compressed after the input exceeds
the Threshold.
Release Time 0–100
Sets the time it takes for the compres-
sion to be released after the input falls
below the Threshold.
Threshold
-60–0 [dB]
(1 dB Step)
Sets the level at which compression
begins.
Ratio
1:1.0, 1:1.1, 1:1.2,
1:1.4, 1:1.6, 1:1.8,
1:2.0, 1:2.5, 1:3.2,
1:4.0, 1:5.6, 1:8.0,
1:16, 1:INF
Compression Ratio
This is a stereo compressor (limiter) that is applied to the nal output.
With separate settings for the high-frequency range, midrange, and low-frequency range, this reduces inconsistencies in volume levels by compressing
the sound when the volume exceeds a preset volume level.
