INST edit section
Sequencer
section
Here you can adjust the character of
each instrument.$
You can use 11 different instruments
(BD–CH) in a pattern.
LEVEL knob
TONE knob
TUNING knob
DECAY knob
SNAPPY knob
Instrument select switch
BASIC VARIATION switch
Measures selector
I/F-VARIATION switch
START/STOP button
PRE-SCALE switch
Adjusts the volume of the instrument.
In the case of the bass drum and
snare drum, this adjusts the tension of
the head. In the case of the cymbal,
this adjusts the character of the sound.
Adjusts the pitch of a tom or conga.
Adjusts the decay.$
Turn the knob toward the left for a
crisp sound, or toward the right for a
more extended sound.
Controls the sound of a snare drum’s
wire snare.$
Turn the knob toward the left for a
sound without the wire snare.
Selects an instrument. It is not
possible to play or write both of these
instruments
simultaneously.
LOW CONGA - LOW TOM
MID CONGA - MID TOM
HI CONGA - HI TOM
CLAVES - RIM SHOT$
MARACAS - HAND CLAP
This switch selects a variation of the
basic rhythm.$
The A (or B) position repeats the A (or
B) rhythm pattern. The AB position
alternately repeats rhythm patterns A
and B.
Selects the interval at which a fill-in is
automatically inserted (auto fill-in).
MANUAL (a fill-in is not inserted
automatically) 16, 12, 8, 4, 2 (units of
measures)
Selects the variation of intro and fill-in.
Plays/stops the rhythm pattern.
Selects the note length of a step.
1: 8th note triplet
2: 16th note triplet
3: 16th note
4: 32nd note
