6
Panel Descriptions
9
Track Section
[KICK] button
Selects the KICK track.
[SNARE] button
Selects the SNARE track.
[HI-HAT] button
Selects the HI-HAT track.
[KIT] button
Selects the KIT track.
[BASS] button
Selects the BASS track.
[INST 1] button
Selects the INST 1 track.
[INST 2] button
Selects the INST 2 track.
[VOCAL] button
Selects the VOCAL track.
* The VOCAL track can only be selected when the workow is in the “SONG”
phase.
[MOTION] button
Turns motions on/o (p. 29).
[INPUT] button
Displays the settings screen for audio input.
Front Panel
1 2
1
PHONES jacks
Connect a pair of headphones that uses either a 1/4-inch phone
type or stereo mini type plug. You can use both plugs at the same
time.
* The same audio signal is output through both PHONES jacks.
2
BUILT-IN MIC
This is the built-in microphone. Use this to record vocals, sample
sounds and capture other audio.
