Rotex HPSU compact (V5) User Manual

8 x Technical data
60
BA ROTEX HPSU compact 2 - 04/2011
8 Technical data
Unit HPSU compact 508 HPSU compact 516
Can be used with an external heat pump unit
RRLQ006BAV3,
RRLQ007BAV3,
RRLQ008BAV3
RRLQ011CA(V3/W1),
RRLQ014CA(V3/W1),
RRLQ016CA(V3/W1)
Dimensions and weights
Dimensions (H x W x D) cm 181 x 79 x 79 181 x 79 x 79
Empty weight kg 124 126
Main components
Water
circulation pump
Type Grundfos UPM2 15-70 CES87 Grundfos UPM2 15-70 CES87
Speed rates PWM PWM
Voltage V 230 230
Frequency Hz 50 50
Protection type IP 42 IP 42
Power consumption A 0.38 0.38
Maximum rated output W 45 45
Heat exchanger
(water/coolant)
Type Brazed metal plate Brazed metal plate
Number 1 1
Volume 0.67 1.01
Minimum flow quantity
(2
l/min 3.5 7
Maximum flow quantity l/min 40 50
Insulation EPP EPP
Storage tank
Total storage capacity litres 500 500
Maximum permissible storage water temperature °C 85 85
Heat consumption at stand-by and at 60 °C kWh/24h 1.4 1.4
Domestic hot water
(stainless steel
1.4404)
Potable water capacity litres 29 29
Maximum operating pressure bar 6 6
Domestic water heat exchanger
surface
m
2
66
Average specific thermal output W/K 2900 2900
Storage tank
charging heat
exchanger (stainless
steel 1.4404)
Water capacity heat exchanger litres 12.6 20.7
Heat exchanger surface area m
2
2.5 4.4
Average specific thermal output
W/K 1200 2090
Solar heating backup
(stainless steel
1.4404)
Water capacity heat exchanger litres 8.6 8.6
Heat exchanger surface area m
2
1.8 1.8
Average specific thermal output W/K 870 870
