1 Important Information
In general every RTK controller is pre-set for its particular control function
so that the controller will in principle do its control work:
Since the dynamic behavior of the controlled system is not known,
default values have been set for the controller's normal (PID) function.
These values (PID-> XP1; Tn1; Tv1) have to be adjusted to the controlled system
( see p.15-16).
Under some circumstances it may also be necessary to set the neutral zone (Xsh) and the
motor running time (Tm)
( see p.15-16).
In the case of motor control valves with remote resistance sensors for posi-
tion feedback the controller must be adjusted to suit the remote resistance
sensor.(see p.14)
