- 36 -
Set value function
Text 1 Description Range of settings Default
Setpt
Set parameter
LC+
Bandwidth upper limit 0....9999 `-------´(off)
LC-
Bandwidth lower limit 0....9999 `-------´(off)
W0
Lower set-value limit for Weff -999...9999
W100
Upper set-value limit for Weff -999...9999
W2
Supplementary set value -999...9999
Grw+
Set value gradient plus for W (w/min) 0.01...99.99 `-------´(off)
Grw-
Set value gradient minus for W (w/min) 0.01...99.99. `-------´(off)
Grw2
Set value gradient W2 for W (w/min) 0.01...99.99 `-------´(off)
Alarm functions
Text 1 Description Range of settings Default
LIM1 Alarm1
LimL1
Lower limit -999...99999 `-------´(off)
LimH1
Upper limit -999...99999 `-------´(off)
Lxsd1
Switch difference -999...99999 1
LIM2 Alarm2
LimL2
Lower limit -999...99999 `-------´(off)
LimH2
Upper limit -999...99999 `-------´(off)
Lxsd2
Switch difference -999...99999 1
Standard algorithm
Text1 Description Range of values Default
Para
PID control parameter
XP1
Proportional range 0.1...999.9%
TN1
Reset time 0...9999 s
TV1
Rate time 0...9999 s
CPara
Control parameter
Tpuls
Min. pulse duration 0.1...999.9 s 0.5
Tm
Motor running time of the actuator 10...9999 s 60
Y2
Supplementary control value -105...105% 50
Ymin
Lower manipulated variable limit -105...105% -105...105%
Ymax
Upper manipulated variable limit -105...105% -105...105%
Y0
Operating point of manipulated variable -105...105% 0
Xsh
Neutral zone 0.2...999.9% 0.2
Xsh1
Neutral zone Xw<0 (only for continuous controller) 0.0...999.9% 1
Xsh2
Neutral Zone Xw>0 (only for continuous controller) 0.0...999.9% 1
