Salus iT500 User Manual

iT500 User Reference Manual
25
iT500RX Thermostat Receiver Controls
The iT500RX provides manual control of the system in the event that the wireless connection fails.
Ch Aux Ch/Aux
Auto Manual Off
Auto - Manual - O - switches
Auto -system controlled by
programs in iT500TR Control
Thermostat
Manual - system continuously on
O - system continuously o
Ch - Aux - Ch/Aux - switches
Should be set to match controlled
system i.e.:
Ch -heating only, 1 zone
Aux - heating only, 2 zones
Ch/Aux - heating (1 zone) plus
hot water

Salus iT500 Specifications

General

Frequency	868 MHz
Interface	Z-Wave
Control type	Touch
Product color	Black, Silver
Smart thermostat	Yes
Units of measurement	°C
Maximum outdoor range	30 m
Temperature range (T-T)	5 - 35 °C
Battery type	AA
Operating voltage	2 V
Number of batteries supported	2
Handheld remote control	No

Weight and Dimensions

Depth	30 mm
Width	128 mm
Height	95 mm
